70mm 1.2″ Fixed Focal Length Lenses | MFA121 COOLENS®

Model NO.    :

MFA121-U70

•Up to 1.2″, C-Mount Lenses
•Up to 25 MegaPixels, 2.74μm Pixel Size Sensors
•Variable Aperture, Excellent Uniformity
•Focal Length 70mm

Model NO. MFA121-U70 Focal Length f=70mm
Max Diameter(RATIO) F=4.0~16 Supported Camera Resolution 25M
Angle H 1'' 9.2° 1.1" 10.4° 1.2" 10.3°
V 7.2° 7.8° 9.3°
D 11.7° 12.9° 13.9°
Distortion(TV) <0.08% Focus Distance(min) 0.5M
Flange Back 17.526mm in air Back Focus 19.6mm in air
Filter Screw Size M35.5x0.5 Dimension Φ38.6x79.42mm
Mount C-Mount Temperature Range -10~+50°C
Flange Back -20~+60°C

Dimensions
