FOV150 MDR9 Relay Lens | RL09150B LONTRY®

Model NO.    :

RL09150B

• Suitable for ultra wide angle testing within 150°
• Suitable for auto focusing and terminal testing
• High resolution

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL09150B 150° 9mm 5mm 4.2kg 400-INFmm <60% Φ185x75.48mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 139.78 425.15 239.15 390.24 292.68
1000 168.55 482.07 271.16 442.48 331.86
5,000 186.71 518.06 291.41 475.52 356.64
Infinite distance 191.60 527.74 296.85 484.40 363.30
