FOV90 MDR40 Relay Lens | RL4090 LONTRY®

Model NO.    :

RL4090

• Big MDR
• Low distortion
• Suitable for focusing of AA stand and module
• Strong universality

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL4090 90° 40mm 5.5mm 1.6kg 300-INFmm <1% Φ155x56.6mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 150.74 378.09 212.68 347.04 260.28
1000 258.15 225 126.56 206.52 154.89
5,000 408.26 355.83 200.15 326.81 244.96
Infinite distance 413.28 828.35 465.94 760.32 570.24
