Beam100-Telecentric Illuminators | COOLIGHT®

Model NO.    :


•Optically Collimated Light for Increased Edge Contrast
•Superior Collimation Ideal for use with Telecentric Lenses
•Beam Diameter 100mm
•Ideal for Use with High Resolution Cameras

Model NO. DTCL-100H-xW-y Color Red-630nm
Beam Dia. (mm) 100 Green-520nm
Working Distance(mm) 86-172 Blue-460nm
Diameter (mm) 142 White-/
Power 1W/3W Voltage 12V~24V
Length (mm) 266.6 Compatible Lens DTCMxxx-100H
Electricity 350mA/750mA


Download datasheet & 3D files
