FOV120 MDR30 Relay Lens | RL30120 LONTRY®

Model NO.    :

RL30120

• High revivification
• Suitable for AA and focus test of wide-angle products within 120°

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL30120 120° 30mm 4.5mm 4.8kg 5000-INFmm <32% Φ190x90.16mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 272.1 581.5 327.1 533.8 400.3
1000 279.2 592.6 333.3 543.9 407.9
5,000 282.8 598.3 336.5 549.1 411.9
Infinite distance 286.5 604.1 339.8 554.5 415.9
