FOV125 MDR11 Relay Lens | RL11125 LONTRY®

Model NO.    :

RL11125

• Ultra wide angle of 125°
• Distortion less than 0.2%
• Compact equipment with small chart and short test distance

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL11125 125° 11mm 4mm 3.32kg 700-INFmm <0.2% Φ199x102.15mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 73.53 430.38 242.09 395.04 296.28
1000 96.10 521.12 293.13 478.32 358.74
5,000 116.49 603.04 339.21 553.52 415.14
Infinite distance 122.59 627.53 352.99 576.00 432.00
