FOV130 MDR6 Relay Lens | RL06130D LONTRY®

Model NO.    :

RL06130D

• High revivification
• Suitable for wide-angle testing within 130°
• Suitable for array testing of terminal products
• Easy to install

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL06130D 130° 6mm 4mm 0.23kg 500-INFmm <30% Φ74x28.7mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 193.71 486.39 273.60 446.45 334.84
1000 257.38 629.22 353.94 577.55 433.16
5,000 309.63 746.40 419.85 685.10 513.83
Infinite distance 325.90 782.89 440.37 718.60 538.95
