FOV45 MDR40 Relay Lens | RL4045 LONTRY®

Model NO.    :

RL4045

• Micro lens
• Big exit pupil diameter up to 18mm
• Suitable for telephoto/periscope lens testing
• Suitable for array testing
• Suitable for focusing and terminal testing

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL4045 45° 40mm 18mm 0.1kg 300-INFmm <0.3% Φ58x34.17mm
Structural Dimension Drawing

Optical Properties



Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 231.20 183.32 103.12 168.26 126.20
1000 315.16 234.18 131.73 214.95 161.21
5,000 425.37 300.95 169.28 276.24 207.18
Infinite distance 463.49 324.05 182.28 297.43 223.08
