FOV90 MDR17 Relay Lens | RL1890-666 LONTRY®

Model NO.    :

RL1890-666

• Customized product
• Low distortion and small lens
• Suitable for terminal test of products within 90°
• Cost-effective

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL1890-666 90° 17mm 3mm 0.127kg 300-INFmm <0.2% Φ68x19.03mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 70.19 217.89 122.57 200.00 150.00
1000 98.65 270.67 152.25 248.44 186.33
5,000 120.28 310.88 174.87 285.35 214.01
Infinite distance 126.72 322.71 181.52 296.21 222.16
