FOV45 MDR10 Relay Lens | RL1045 LONTRY®

Model NO.    :

RL1045

• Micro lens
• Big exit pupil diameter up to 8mm
• Suitable for telephoto/periscope lens testing
• Suitable for array testing

Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL1045 45° 10mm 8mm 0.2kg 400-INFmm <0.45% Φ30x12mm



Structural Dimension Drawing

Optical Properties





Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 191.55 143.20 80.55 131.44 98.58
1000 274.43 199.24 112.07 182.88 137.16
5,000 352.15 251.79 141.63 231.12 173.34
Infinite distance 378.43 269.57 151.63 247.43 185.57
