FOV120 MDR7 Relay Lens | RL07120 LONTRY®

Model NO.    :

RL07120

• Small lens
• Low distortion
• Suitable for imaging testing within 120°
• Suitable for array testing of terminal products



Model NO. FOV angle MDR Aperture Weight Range of simulated distance Distortion Outline dimensions
RL07120 120° 7mm 4mm 0.16kg 300-INFmm <2% Φ70x23.48mm
Structural Dimension Drawing

Optical Properties

Structure and Size
WDV (mm) Distance from the camera module to the simulated imaging position WDC (mm) Distance from the relay lens object end to the test card Test card dimensions (LXW)
16:9 4:3
Length (mm) Width (mm) Length (mm) Width (mm)
400 156.29 508.48 286.02 466.72 350.04
1000 215.40 681.69 383.45 625.71 469.28
5,000 266.49 831.40 467.70 763.10 572.30
Infinite distance 282.90 879.51 494.72 807.28 605.46
