35mm 1/1.8″ Fixed Focal Length Lenses | MFA118 COOLENS®

Model NO.    :


•Up to 1/1.8″, C-Mount Lenses
•Up to 6 MegaPixels, 2.4μm Pixel Size Sensors
•Variable Aperture, High Resolution, Ruggedized Design
•Focal Length 35mm

Model No. MFA118-S35V2 Mount C-Mount
Focal Length 35mm Back Focal Length 13.9 mm in Air
F NO. F2.8 - F16 Filter Size M27 x P0.5
Max. Image Format 1/1.8" (φ9.4mm) Distortion <0.05%
Angle of View D 1/1.8" 13.2° 1/2" 11.8° 1/3" 8.9°
H 10.9° 9.5° 7.1°
V 7.3° 7.1° 7.1°
M.o.D 0.15m Object Dimension at M.o.D 1/1.8" 31.63mm x 21.09mm
Weight 57.1g 1/2.3" 27.63mm x 19.80mm
Flange Back Length 17.526mm in Air
Structure 5 Groups, 7 Elements Operating Temperature -10°C — 50°C
Operation of Iris Range F2.8 - F16 Operation of Focus Range MOD-INF
Spectral Transmission AT 436nm-656nmT≥85%
