16mm 1/1.8″ Fixed Focal Length Lenses | MFA118 COOLENS®

Model NO.    :


•Up to 1/1.8″, C-Mount Lenses
•Up to 6 MegaPixels, 2.4μm Pixel Size Sensors
•Variable Aperture, High Resolution, Ruggedized Design
•Focal Length 16mm

Model No. MFA118-S16V2 Mount C-Mount
Focal Length 16mm Back Focal Length 12.7mm in Air
F NO. F2.8 - F16 Filter Size M27 x P0.5
Max. Image Format 1/1.8" (φ9.4mm) Distortion <0.06%
Angle of View D 1/1.8" 31.0° 1/2" 27.8° 1/3" 21.1°
H 25.7° 22.4° 16.9°
V 17.3° 16.9° 12.7°
M.o.D 0.1m Object Dimension at M.o.D 1/1.8" 55.02mm x 36.68mm
Weight 39.5g 1/2.3" 48.06mm x 34.45mm
Flange Back Length 17.526mm in Air
Structure 5 Groups, 7 Elements Operating Temperature -10°C — 50°C
Operation of Iris Range F2.8 - F16 Operation of Focus Range MOD-INF
Spectral Transmission AT 436nm-656nmT≥85%
