6mm 1/1.8″ Fixed Focal Length Lenses | MFA118 COOLENS®
Model NO. :
MFA118-S06V3
•Up to 1/1.8″, C-Mount Lenses
•Up to 6 MegaPixels, 2.4μm Pixel Size Sensors
•Variable Aperture, High Resolution, Ruggedized Design
•Focal Length 6mm
Model No. | MFA118-S06V3 | Mount | C-Mount | ||||
Focal Length | 6mm | Back Focal Length | 11.6 mm in Air | ||||
F NO. | F1 - F2 | Filter Size | M25.5 x P0.5 | ||||
Max. Image Format | 1/1.8" (φ9.4mm) | Distortion | <1.5% | ||||
Angle of View | D | 1/1.8" | 74.8° | 1/2.5" | 68° | 1/3" | 53.6° |
H | 63.5° | 56.6° | 43.8° | ||||
V | 44.8° | 43.8° | 32.3° | ||||
M.o.D | 0.08m | Object Dimension at M.o.D | 1/1.8" | 128.67 mm x 85.78mm | |||
Weight | 32.2g | 1/2.3" | 112.39mm x 80.56mm | ||||
Flange Back Length | 17.526mm in Air | ||||||
Effective Lens Aperture | Front | φ18.12mm | Operating Temperature | -10°C — 50°C | |||
Rear | φ5.81mm | Operation of Focus | Range | MOD-INF | |||
Spectral Transmission | AT 436nm-656nmT≥85% | Operation of Iris | Range | F2.8 - F16 |
